- Excellent workmanship: the circuit board is purely hand-made lap-welded, the chassis is coated with transparent piano lacquer, high-end vacuum electronic tube, with z11 as the core of the power and output transformers which is well shielded, Japanese A*LPS motor potentiometer, German high quality capacitors.
- An Integrated Class A Tube Amplifier : A pair of Russian 12AX7EH and 6SN7EH vacuum tubes are used in the front stage, while a pair of KT170 (Russian TUNG-SOL Tissot) vacuum tubes are used in the rear stage for single-ended A-class power amplification.
- Five sets of signal inputs (BALANCE、 CD、LINE、PHONO、PRE IN), these can meet your different applications. This amplifier has a balanced input feature and a pure power amplifier function. With MM phono stage, this amplifier can work with your turntable to let you enjoy the music from vinyl.
- Pleasant and Dynamic Sound: The mid-high frequencies are particularly smooth with good density, suitable for appreciating different music in style.
- The infrared remote control can let you operate this amplifier easily, and the exquisite tube cage is easily removable by hand.
Technical specifications:
Rated output power: 28W 28W
Harmonic distortion: 1% (1KHZ)
Frequency response: 20Hz~50KHZ
Signal to noise ratio: 92dB
Left and right output balance:<1dB
Output impedance: 4 Ω, 8 Ω, 16 Ω
Input impedance: 100K Ω
Power consumption : 270W
Net weight: 36KG
Gross weight: 41KG
Input sensitivity: 165mV (-1.5dB) 180mV (-3db) 1.5V (pre in)
vacuum tubes: 12AX7EH x2, 6SN7EH x2, KT170x 2, 274B x 2
Whole machine volume (Wx Dx H): 430x 393x228 (mm)
Power supply voltage:~115V/230V 5% (50Hz-60Hz)
Working conditions: Temperature range of 0 ℃ to 40 ℃
Humidity: 20%~80%
Storage conditions: Temperature -20 ℃~70 ℃ Humidity: 20%~90%
- Item Weight : 97 Pounds
- Date First Available : March 30, 2025
- Manufacturer : Zhuhai Meishi Audio Equipment Co., Ltd
- Country of Origin : China
